Quick Answer
The most common cause is a blown F81 fuse (20A) located in the engine compartment fuse block. If the fuse is functional, inspect the 7-pin connector for corrosion and ensure the trailer’s ground wire is properly secured.
TL;DR – Quick Summary
Resolve 2016 Dodge Ram trailer running light failures by first checking fuse F81 in the Power Distribution Center. Inspect the 7-pin plug for corrosion and verify a solid ground connection. If the fuse is intact, the issue likely stems from damaged wiring or a faulty TIPM relay.
📌 Key Takeaways
- ✅ Check the 20A or 30A trailer tow fuses in the engine compartment PDC first.
- ✅ A multimeter is essential for testing voltage at the 7-way blade connector.
- ✅ Corroded ground wires often cause intermittent running light failures.
- ✅ Modern Rams may require a TIPM (Totally Integrated Power Module) reset or repair.
- ✅ Always verify trailer-side functionality before dismantling truck wiring.
Dealing with a Dodge Ram trailer running lights not working issue can be frustrating and unsafe. Our community relies on functional towing equipment for work and play. Whether you are in our local serving area or passing through, understanding the Power Distribution Center and specific fuse configurations is essential. Professional diagnostic support is available at our location to restore your vehicle’s towing integrity.
Identifying Trailer Tow Fuse and Relay Locations
When the running lights (often referred to as parking lights or tail lights) on your trailer fail to illuminate, the first point of failure is typically the Power Distribution Center (PDC). In a 2016 Dodge Ram, the PDC is located under the hood on the driver’s side, housed in a black plastic box. Unlike older vehicles where a single fuse might control all exterior lighting, the Ram utilizes a sophisticated electrical architecture that separates the truck’s lighting from the trailer’s lighting to prevent a short in the trailer from disabling the vehicle’s primary safety systems.
For the 2016 model year, you must look specifically at the Trailer Tow Park Lamp circuit. In most Ram 1500, 2500, and 3500 configurations from this era, the fuse to inspect is Fuse F106 (20 Amp Yellow). This fuse is dedicated specifically to the trailer’s running light circuit. If this fuse is blown, your truck’s tail lights will function perfectly, but the 7-way or 4-way connector at the rear will lack the necessary 12V output for the trailer’s markers.
Always use a test light or multimeter to check fuses rather than a visual inspection. Micro-fractures in the fuse element can be invisible to the naked eye but will still result in an open circuit. Check for power on both small metal tabs on top of the fuse while it is seated and the vehicle lights are turned on.
If Fuse F106 is intact, the next component in the sequence is the trailer tow park lamp relay. On many 2016 models, this relay is “non-serviceable,” meaning it is soldered directly onto the internal circuit board of the Integrated Power Module (IPM). This design choice by FCA (Fiat Chrysler Automobiles) means that if the relay fails, the traditional fix is a complete replacement of the PDC—a costly endeavor that we help our customers avoid through advanced bypass solutions.
Testing the 7-Way Connector and Wiring Harness
Before assuming the truck’s computer or PDC is at fault, we must verify the output at the bumper. The 7-way round connector is the industry standard for the 2016 Dodge Ram, and it is prone to corrosion, especially for those living in regions where road salt is prevalent. Professional-grade diagnostics involve testing the specific pins to isolate the truck from the trailer.
- Activate the Circuit: Turn on the vehicle’s headlight switch to the “On” position (not “Auto”).
- Identify Pin 3: On a standard 7-way RV blade connector, the “Tail/Running Lights” pin is located at the 11 o’clock position (Pin 3).
- Measure Voltage: Using a multimeter, place the positive lead on Pin 3 and the negative lead on Pin 1 (Ground – 7 o’clock position). You should see approximately 12.4V to 14.2V depending on whether the engine is running.
- Check for Continuity: If voltage is absent, inspect the back of the plug where the wiring harness enters the housing. It is common for the wires to pull out or corrode at the terminal crimp.
| Pin Number | Function | Wire Color (Typical) |
|---|---|---|
| Pin 3 | Running/Tail Lights | Brown / Green |
| Pin 1 | Ground | White |
| Pin 4 | 12V Battery Charge | Black / Red |
If you have power at the truck’s bumper but the trailer lights still don’t work, the issue lies within the trailer’s wiring. A common accessible point of failure is the trailer’s “ground to frame” connection. A weak ground will often allow low-draw LEDs to flicker but will prevent incandescent bulbs from illuminating entirely.
Common Causes: Blown Fuses vs. Integrated Power Module Issues
The 2016 Ram utilizes a Totally Integrated Power Module (TIPM) or a variation of the Power Distribution Center that manages current via internal logic. This presents a unique challenge: the system can “lock out” a circuit if it detects an over-current condition (a short) to protect the module. Even after you fix the short on the trailer, the truck might not send power to the lights until the code is cleared or the system is power-cycled.
✅ Pros of TIPM Repair Kits
- Significantly lower cost than module replacement
- Eliminates the need for dealer programming
- Provides a serviceable external relay
- Available at our convenient local facility
❌ Cons of Full Module Replacement
- Expensive ($800 – $1,200 parts + labor)
- Requires VIN programming and configuration
- Internal relays can fail again in the future
- Long lead times for OEM parts
The most nuanced issue we see at our location is the “phantom voltage” phenomenon. A digital multimeter may show 12V at the 7-way plug, leading the owner to believe the truck is fine. However, because the internal TIPM relay is failing, it cannot carry the amperage required to actually light the bulbs. As soon as a load (the trailer) is connected, the voltage drops to zero. We use dedicated load-testers to ensure the circuit is robust enough to handle the 5-10 amps required for trailer markers.
Do not attempt to “jump” power from the truck’s tail light wiring directly to the trailer plug. The 2016 Ram uses a Pulse Width Modulation (PWM) signal for its own lights, and the additional current draw from a trailer can fry the truck’s main lighting control module, leading to much more expensive repairs.
Professional Diagnostic Services at Our Local Facility
Our trusted local technicians specialize in heavy-duty truck electrical systems and have seen every variation of the 2016 Dodge Ram trailer running lights not working. We serve the local community with high-tech diagnostic tools that interface directly with the vehicle’s CAN bus system to see exactly what the Power Distribution Center is reporting.
By visiting a nearby expert facility, you gain access to specialized knowledge that goes beyond a simple fuse swap. Our diagnostic process includes:
- Computerized Scan: We check for “B” and “U” codes in the Body Control Module that indicate circuit faults.
- Pin-Drag Testing: We ensure the terminals in your 7-way connector are tight and making proper contact; loose pins are a common cause of intermittent lighting.
- Harness Inspection: We trace the wiring from the PDC to the rear bumper, looking for accessible locations where the harness may have rubbed against the frame.
- Relay Bypass Installation: If your internal TIPM relay has failed, we offer a professional bypass kit that restores functionality safely and affordably.
Restoring your towing capabilities shouldn’t be a guessing game. Our location is equipped with the latest technical bulletins and wiring schematics specifically for the 2016 Ram 1500-3500 series. Whether you use your truck for hauling horses, construction equipment, or a weekend camper, ensuring your running lights are functional is a legal requirement and a safety priority.
“Modern truck electrical systems are no longer just wires and switches; they are networked computers. Treating a lighting issue like a 1990s pickup can lead to catastrophic module failure. Always verify the logic before you verify the wire.”
Conclusion: Get Back on the Road Safely
Solving a “2016 Dodge Ram trailer running lights not working” issue requires a methodical approach—starting with Fuse F106 and moving through the complex Integrated Power Module logic. If you’ve checked your fuses and your trailer still sits in the dark, it’s time for professional intervention. Don’t risk a roadside citation or a collision due to poor visibility.
Contact us today or visit our convenient location to speak with a trusted local expert. Our team is ready to provide the professional diagnostic services you need to keep your truck and trailer moving safely. We pride ourselves on serving our community with integrity, speed, and precision.
